Liquid Handler

The Oasis LM 600 Liquid Handling Robot is a versatile and robust open platform for any liquid handling application, providing state-of-the-art performance in precision and accuracy. Compared to the industry standard belt driven and rotary motor and encoder system, the non-contact brushless linear with linear encoder motion control technology of the Oasis LM provides superior speed and positional accuracy, down to 0.001 mm repeatability at 2G of acceleration. Combined with the extensive host of available Options and Accessories, the Oasis 600 LM platform is the most compact and powerful bench top workstations available. Offering 8 axis of freedom, eighteen microplate positions, a Quick Deck conveyor based plate transport and a menu of available pipetting tools, accessories and configurations. The Oasis LM 600 liquid handling robot provides the efficient automation of the most challenging drug screening protocols. Both the software and instrument chassis provides simple external integration capabilities with all four sides of the worktable accessible by the use of existing laboratory microplate storage, handling detection and processing systems. Currently, the product is offered with the capability to configure any combination of available or custom arm tool providing further versatility for application development. The flexible 18 position worktable allows any combination of multiple users and / or protocols. The Oasis LM 600 is controlled by the proven and flexible Method Manager Software that you have come to expect from the Oasis Series of workstations. Combine Method Manager Software along with the host of available options and accessories and the LM 600 provides and extremely compact, requiring only 25” of depth for the legs, and powerful bench top workstation with either the 96 or the 384 Heads. The OASIS LM 600 Starts with the best robotic device and adds: A compact & open platform A host of options & accessories An intuitive multi-level, multi-user software Bench Top - Gantry Robotic Workstation Linear Motor & Encoder Technology Up to 14 –Axis of Freedom Most Efficient Worktable – 18 plates in 24” One or Two Tool Arms Host of Options & Accessories Safety Hood & Interlock Switch Modular Worktable Standardized Hardware Multi Level & Multi-User GUI Software One Active Deck Option All 4 Sides Available for External Integration Broad Range of Applications Pre-Configured Application Solutions Convenient Serviceability Features Why Settle for Less: Highest Speed Most Efficent Worktable Most Accurate Motion Control Multiple Tool Arms Two Sizes to Choose from 600 & 1200 MM Designed by Integrators for Integration Liquid Handling Robot Platform 1 or 2 Tool Arms High Precision Linear Servo Motors & Encoders Universal Power Supply Most Efficeient Worktable Layout Flexible Integration Hooks Custom Worktables Active Worktable Accessories 5 Axis of robotic motion Multi-Tasking of Tool Arms (Parallel & Indepent use of both tool arms) Tools Custom Tools 96, 384 or 1536 Plate Pipetting MicroArray Printing Plate Gripping 96 & 384 Tip Disposable & Fixed Tip Pipette Heads Options T-Rx Tray Exchange System Tip Washer Independent Channel Pipetting or reagent dispensing Refillable Reagent Sations Heating/Cooling Stations Magnetic/Vacuum Filtration Stations Mircro Array PrintHeads Sonication Station Magnetic Reagent Stirrer Micro Plate Shaker UPS System Safety Safety Enclousre W/ safety Interlocks Automatic Pause & Recovery Function Universal Power Supply Software Easy Method Development Error Handling Integration Hooks Execute Methods by Line VB Scripting Service All components Easily Accesiable Modular Design means modular Service One Motion Controller, One Cable and One Connector All Electronics above worksurface out of the way of spills Linear Motors provide a non-mechanicl and non-wear system Remote Diagnostic and preventative Maintainence capabilty through internet connectivity

Configuration shown is for demonstration purposes. Contact us to discuss your application and needs for a customized quote.
